Item Description
Cummins TRU1600 Natural Gas Generator Set, 60 Hz, 800 kW / 1000 kVA Rated Output, Cummins K50N-G10S 50.3L V16 Natural Gas Engine, 1800 RPM, Turbocharged & Aftercooled, ECU Controlled, 24V DC Electric Start, Includes Two-Year Unlimited-Hour Warranty.
Generator Specifications
Manufacturer: Cummins
Model: TRU1600
Fuel Type: Natural Gas
Frequency: 60 Hz
Rated Power: 800 kW
Rated Apparent Power: 1000 kVA
Rated Engine Speed: 1800 RPM
Engine
Engine Manufacturer: Cummins
Engine Model: K50N-G10S
Engine Displacement: 50.3 L
Engine Configuration: V16
Number of Cylinders: 16
Engine Cycle: 4-Cycle
Bore x Stroke: 159 x 159 mm
Aspiration: Turbocharged & Aftercooled
Compression Ratio: 11.5:1
Engine Controls: ECU
Fuel Type: Natural Gas
Electrical System
Starting System: 24V DC Electric Start
Frequency: 60 Hz
Generator Output: 800 kW / 1000 kVA
Engine Speed: 1800 RPM
Category Specific (Generator Set)
Generator Type: Industrial Natural Gas Generator Set
Prime Mover: Cummins K50N-G10S
Rated Output: 800 kW
Rated Capacity: 1000 kVA
Frequency: 60 Hz
Fuel: Natural Gas
Electronic Engine Control: Yes
Turbocharged: Yes
Aftercooled: Yes
Electric Start: Yes
Powertrain / Engine Configuration
Cylinder Arrangement: V-Type
Cylinders: 16
Displacement: 50.3 L
Bore x Stroke: 159 x 159 mm
Operating Speed: 1800 RPM
Engine Cycle: 4-Stroke
Compression Ratio: 11.5:1
Warranty
Warranty Term: 2 Years
Hour Limitation: Unlimited Hours
Additional Features
Cummins K50N-G10S Natural Gas Engine
ECU Electronic Controls
Turbocharged Induction System
Aftercooled Engine
24V DC Starting System
60 Hz Generator Configuration
Equipment specifications, output ratings, dimensions, warranty coverage, and included components are approximate and subject to verification. Please contact your sales representative for the most current information and complete warranty terms.
