Financing Category
Condition
Used
Item Number
#1996
Make
volvo
Model
A25G
Year
2023
Industry
construction
Equipment Type
articulated dump trucks
Location
Ft. Worth, TX
Hours
4066
Also Available In
| Year | 2023 |
| Make | volvo |
| Model | A25G |
| Hours | 4066 |
| Condition | Used |
| Dump Angle | 74 degrees |
| Capacity - Heaped | 20.02 yd3 |
| Capacity - Struck | 15.83 yd3 |
| Voltage | 24 V |
| Starter Motor | 9 |
| Battery | 2x12 |
| Plate Thickness-Bottom | 0.6 in |
| Plate Thickness-Chute | 0.6 in |
| Transmission | PT 2116 |
| Transmission Type | Automatic |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 2 |
| Max Speed | 32.8 mph |
| Total Empty | 49493.8 lb |
| Total Loaded | 104609.4 lb |
| Maximum System Pressure | 3626 psi |
| Horsepower, Gross-Sae J1995 | 315 hp |
| Horsepower Per Sae J1349 Net | 314 hp |
| Max Engine Speed | 2100 |
| Engine Make | Volvo |
| Engine Model | D11L |
| Gross Torque | 1438.3 lb ft |
| Net Torque | 1432.4 lb ft |
| Displacement | 659 cu in |
| Fuel Tank | 100.4 gal |
| Hydraulic Tank | 36.2 gal |
| Cooling System | 12.7 gal |
| Def Tank | 10.4 gal |
| Transmission | 10.9 gal |
| Crankcase | 9.3 gal |
| Brake Cooling System | 9.3 gal |
| Dropbox | 2.4 gal |
| Overall Length | 33.53 ft in |
| Overall Width | 16.94 ft in |
| Overall Height | 11.02 ft in |
| Wheelbase | 9.07 ft in |
| Ground Clearance | 1.71 ft in |
| Dump Height | 21.43 ft in |
| Dump Ground Clearance | 2.23 ft in |
