Actual Air Delivery: 185 cfm (5.2 m³/min) Rated Pressure: 100 psi (7 bar) Pressure Range: 80 psi minimum to 125 psi maximum (5.5 bar to 8.6 bar) Compressor Type: Rotary screw (Direct drive) Service Valves: 2 x 3/4” NPT discharge outlets Compressor Oil Capacity: 2.1 gallons (7.9 L) Noise Level: 76 dBA at 7 meters Engine Manufacturer/Model: Kubota V2403 (Naturally aspirated) Emissions Tier: Tier 3 (Stage III Compliant — No DEF or DPF required) Engine Displacement: 4-cylinder, 2.4L (148.5 cu in) Operating Speed: 2720 rpm Fuel Consumption (Full Load): ~2.7 gallons per hour (10.2 L/h) Fuel Tank Capacity: 27 gallons (102 L) Maximum Operating Altitude: 9,000 ft Working Weight (Wet): 2,075 lbs to 2,175 lbs (942 kg to 986 kg) Overall Length (Including Tow Bar): 131 in (3327 mm) Overall Width: 59 in (1499 mm) Overall Height: 58 in (1473 mm) Track Width: 51 in (1295 mm) Tire Size: ST175/80D13 Axle Rating: 3,700 lbs independent torsion suspension Canopy Style: Clamshell canopy with gas-assisted struts Material Construction: Galvanneal sheet metal with a powder-coated finish System Voltage: 12V DC Battery Rating: 1000 CCA Safety System: SSAM annunciator module (Shutdown for high compressor temp, high engine coolant temp, low engine oil pressure)
