Operating Weight: 56,830 lbs Engine: Isuzu 4HK1 4-cylinder turbocharged diesel Engine Power: 159 hp at 2,000 rpm Emissions Rating: EPA Final Tier 4 compliant Max Digging Depth: 21 feet 8 inches Max Digging Reach: 33 feet 2 inches Max Dump Height: 29 feet 3 inches Bucket Breakout Force: 35,320 lbf Tail Swing Design: Reduced tail-swing profile Tail Swing Radius: 5 feet 6 inches Main Hydraulic Flow: 162 GPM total from a 3-pump system Fuel Tank Capacity: 100 gallons Hydraulic Tank Capacity: 343 gallons Track Length on Ground: 12 feet 0 inches Overall Width: 10 feet 6 inches with standard 32-inch triple semi-grouser shoes Overall Transport Length: 29 feet 11 inches with a standard 9-foot 7-inch arm Overall Transport Height: 9 feet 9 inches to the top of the boom
