Operating Weight: 32,800 lbs (14,900 kg) Engine: Isuzu 4JJ1XDRAC-01 (Tier IV Final compliant) Net Engine Power: 96 hp (71.3 kW) @ 2,000 rpm Bucket Digging Force: 24,800 lbf (110 kN) / 21,900 lb SAE Max Digging Depth: 19′ 7″ (5,980 mm) Max Digging Reach: 28′ 3″ (8,620 mm) at ground level Travel Speed: 3.5 mph (5.6 kph) high / 2.1 mph (3.4 kph) low Drawbar Pulling Force: 31,700 lbf (141 kN) Overall Length: 24′ 8″ (7,530 mm) Overall Width: 8′ 6″ (2,590 mm) Overall Height (to top of boom): 10′ 3″ (3,130 mm) Tail Swing Radius: 7′ 2″ (2,190 mm) Shoe Width: 23.6 in (600 mm
