Item Specifications
Category
Condition
Used
Item Number
#1173
Make
jlg
Model
860sj
Year
2018
Industry
aerial
Equipment Type
telescopic boom lifts
Location
Corpus Christi, TX
Serial
03002*****
Also Available In
TX
Item Description
This 2018 JLG 860SJ telescopic boom lift provides elevated access for construction and facility maintenance. The telescopic boom offers horizontal reach, and continuous rotation helps position the platform without repeatedly moving the machine. Mileage and/or engine hours are approximate and subject to change. Please contact your sales representative for the most current readings.
Specifications
General
| Year | 2018 |
| Make | jlg |
| Model | 860sj |
| Hours | 3226 |
| Serial Number | 03002***** |
| Condition | Used |
| Max Platform Height | 86 ft in |
| Max Horizontal Reach | 75 ft in |
| Platform Capacity - Restricted | 750 lb |
| Platform Capacity - Unrestricted | 500 lb |
| Swing | 360 degrees |
| Swing Type | Continuous |
| Operating Weight | 36230 lb |
| Fuel Capacity | 31 gal |
| Hydraulic System Fluid Capacity | 48 gal |
| Tire Size | 15-625 Pnuematic |
Engine & Powertrain
| Diesel Engine Type | DEUTZ TD 2.9L Tier 4 Final 67 hp |
| Dual Fuel Engine Type | Ford MSG425 84hp |
| Maximum Ground Bearing Pressure | 81 psi |
| System Voltage | 12 V |
Working Range
| Axle Oscillation | 0.7 ft in |
| Drive Speed | 3.5 mph |
Dimensions
| Overall Length | 37.3 in |
| Overall Width | 8.2 ft in |
| Overall Height - Mast Lowered | 10 ft in |
| Ground Clearance | 11 in |
| Turning Radius | 19.8 ft in |
| Platform Dimension A | 3 ft in |
| Platform Dimension B | 8 ft in |
| Tailswing Radius | 4.8 ft in |
2018 JLG 860SJ Telescopic Boom Lift
BUY NOW OR MAKE OFFERAvailable
